ZappPLUS Ionizing Blow-Off System
Portable and flexible, the ZappPLUS Ionizing Blow-off System, with its ZappII Piezonizer, is ideal for neutralizing electrostatic charges and blowing loose, dry, surface contaminants from parts, assemblies and packaging materials in Injection Molding, Medical Device, Industrial, Electronics and Semiconductor applications. The ZappII’s built-in High Frequency Piezoelectric Transformer produces an abundance of balanced ions in an ultra-compact housing. CDA (Clean Dry Air) or nitrogen blowing through the ZappII effectively neutralizes static charges and removes particles from surfaces.
The ZappII and a sensor eye are mounted to the end of an adjustable gooseneck with table-clamp, for easy mounting on the edge of your work surface for quick setup of the system. Simply shape the gooseneck to aim the ZappII nozzle in an ergonomically and process friendly direction for hands-free operation. The sensor detects the presence of your part, sending power and air/nitrogen to the ZappII via the system controller. The distance from the target to the sensor is easily adjusted from a few to many inches to control how close the part must be to turn the system on, helping control process and efficiency.
The ZappPLUS multi-function Controller includes a system On/Off switch, needle valve to adjust the pressure and flow to the ZappII and ‘tri-mode’ switch to change the air/nitrogen from a constant stream to a High (10Hz) or Low (5Hz) Frequency Pulse, excellent for purging particles out of hard-to-clean nooks and crannies. An alarm LED indicates a system failure or excessive contamination of the ZappII. An off-delay timer, programmable from 0-60 seconds, keeps the ionized airflow on if the target momentarily moves out of line with the sensor, handy if the part is optically clear or has openings the sensor sees through.
