BR6100C/BR6100T Static Brush Bar

$49.00$232.00

The BR6100 Static Brush Bar is available in 2 styles:  BR6100C – Carbon Bristles and BR6100T – Thunderon Synthetic Bristles. The BR6100 is a non-powered static reduction device used primarily on webs of paper or plastic. It becomes more efficient as the electrostatic charge on the material increases. Constructed using very fine conductive synthetic filaments secured in a reinforced aluminum housing, the BR6100 is both easy to install and inexpensive to buy and operate.

Clear
SKU: N/A Categories: , ,

Description

The BR6100 Passive Static Brush Bar is available in 2 styles:

  • BR6100C Static Brush Bar  – Carbon Bristles
  • BR6100T Static Brush Bar – Thunderon Synthetic Bristles

Additional information

Weight N/A
Dimensions N/A
Length

6", 12", 18", 24", 30", 36", 42", 48", 54", 60"

Bristle Type

Carbon Bristles, Thunderon Bristles

How It Works

The BR6100 Passive Static Bar is a non-powered static reduction device used primarily on webs of paper or plastic. It becomes more efficient as the electrostatic charge on the material increases. Constructed using very fine conductive synthetic filaments secured in a reinforced aluminum housing, the BR6100 is both easy to install and inexpensive to buy and operate.

The BR6100C is ideal for use in coating machines, flexographic presses or on any machine processing highly charged material in a flammable or explosive environment. In some applications where the web speed exceeds 750 FPM, these bars can be used in conjunction with a Static Clean electrically powered ionizer bars.

Features

  • Easy installation using simple fasteners
  • Low profile for installation in cramped quarters
  • Rapid neutralization of strong static charges without the use of high voltage.
