TSN75E 7.5kV Power Supply

$395.00

The TSN75E 7.5kV Power Supply is an output-current-limited AC-voltage source, providing appropriate ionization at the Applicator and safety to the user. An internal step-up transformer operates off the mains with a high-voltage (HV) secondary coupled to the Output Ports through a resistive damping circuit.

SKU: PSTSN75E Categories: , , ,

Description

The TSN75E 7.5kV Power Supply is an output-current-limited AC-voltage source, providing appropriate ionization at the Applicator and safety to the user. An internal step-up transformer operates off the mains with a high-voltage (HV) secondary coupled to the Output Ports through a resistive damping circuit.

The Resistive Output Coupler provides optimal voltage limiting and load regulation with a wide range of Applicator equipment.  This enhances the reliability of the Neutralizing System. The TSN75E Power Supple includes a dual-voltage selector switch to support operation with a multitude of international main power systems.

Additional information

Weight 6.1 lbs
Dimensions 9 × 8 × 6 in

Features

  • Dual HV-output ports
  • Field-serviceable componentry
  • User-safe current limiting
  • AC ionization for many Applicator systems (e.g. static bar, ionizing air nozzle, and ionizing airknife.
