Statiron DZ4 Digital Field Meter

In order to effectively eliminate the static charges that cause problems, measuring or finding the “hot spots” in your manufacturing process is a fundermental step in determining the type of ionizer required for the application.The static field meter Statiron DZ4 is a lightweight portable meter with digital printout, designed for measuring the static potential on a charged object.

Description

In order to effectively eliminate the static charges that cause problems, measuring or finding the “hot spots” in your manufacturing process is a fundamental step in determining the type of ionizer required for the application. The Statiron DZ4 Digital Field Meter is a lightweight portable static field meter with digital printout, designed for measuring the static potential on a charged object.

Additional information

Weight 1.35 lbs
Dimensions 8 x 8 x 8 in

Application Examples

  • Check the charge condition on film, paper, resin etc. using the DZ4 meter w/ sensor head
  • Check the Ion balance of ionizers in a plant using the DZ4 meter along with the plate option
  • Human Body potentials can be measured using the DZ4 meter with the human plate handle.

Features

  • Visible bright LED window.
  • Easy operation with single button control
  • Two modes available; normal & maximum mode of operation
  • Error indicator if sensor head is damaged
  • Zero point adjustment switch available to bring meter back to zero volts
  • Measuring range is 0-20kV
  • Optional charge plate available to check ion balance of ionizersĀ  (p/n ODZ4-PLT)
  • Optional plate available to measure the static electricity in human bodies (p/n ODZ4-HPLT)
  • Comes standard with 180 degree rotary sensor head, you can measure at various angles
  • Distance between the sensor head and charged object should be 1″ away.
